| Key product |
| AC Input Input rating210 V DC to 300 V DC, 3.5 A to 6 A 100 V AC to 240 V AC, 12 A to 6 A Operating voltage range 210 V DC to 300 V DC 90 V AC to 264 V AC Nominal AC input frequency 50/60 Hz Operating AC frequency range 47 Hz to 63 Hz Efficiency 70% typical Power disconnect The AC/DC power cable provides main power disconnect. Do not position the equipment so that it is difficult to disconnect the power cord. The front-panel power switch causes the internal chassis power supply to provide DC power to the CompactPCI/PXI Express backplane. You also can use the front panel terminal block 4-pin connector and power mode switch to control the internal chassis power supply. Chassis Cooling Forced air circulation (positive pressurization) through six 150 cfm fans (three sets of dual stacked fans) with High/Auto speed selector Slot airflow direction Bottom of module to top of module Module cooling intake Bottom of chassis Module cooling exhaust Along top of chassis Power supply cooling system Forced air circulation through integrated fan Power supply cooling intake Rear of chassis Power supply cooling exhaust Top of chassis |
