Tektronix MCA3000 Microwave Analyzer

The RSA500A Series USB spectrum analyzers offer high performance portable spectrum analysis in a rugged battery-powered package.

Category: Tags: , , ,
Model Max Frequency Time Resolution Frequency Resolution
MCA3040 40 GHz 100 ps 12 digit
MCA3027 27 GHz 100 ps 12 digit



Key performance specifications
  • 27 GHz and 40 GHz models
  • Microwave analyzer channel with CW or Burst
  • Two 300 MHz general-purpose channels
  • 100 ps single-shot time resolution
  • 12 Digit/s frequency resolution, 14 digit display
  • 25 ms (auto) or zero (manual) acquisition Time
  • 3 mV voltage resolution
  • Optional 1.5×10–8 ultra high-stability oven time base



Key Features
  • Measurement throughput
  • 250k Sample/s data transfer rate to internal memory (up to 750k samples stored)
  • 5k sample/s data transfer rate over USB/GPIB bus (block mode)
  • Available functions and features
  • Automated measurements: frequency, period, ratio, time Interval, time interval error, pulse width, rise/fall time, phase angle, duty cycle, maximum voltage, minimum voltage, peak-to-peak voltage
  • Integrated power meter
  • Multi-measurement display
  • Trend plot mode
  • Measurement statistics mode
  • Histogram mode
  • Allan deviation
  • Zero dead-time frequency/period measurements



Connectivity
  • USB device and GPIB ports on rear panel for quick PC connectivity
  • GPIB interface supports full SCPI-compatible programmability and offers an emulation mode for Plug-and-Play replacement in existing ATE systems
  • External arming input
  • 10 MHz reference oscillator output



Optional application software
  • Optional TimeView™ software available for modulation domain analysis
