| Key product |
| AC Input Input voltage range100 to 240 VACOperating voltage range 90 to 264 VAC Input current rating 12 to 6 A Input frequency 50/60 Hz Operating frequency range 47 to 63 Hz Efficiency 70% typical Power disconnect The AC power cable provides main power disconnect. Do not position the equipment so that it is difficult to disconnect the power cord. The front-panel power switch causes the internal chassis power supply to provide DC power to the CompactPCI/PXI Express backplane. You also can use the front panel terminal block 4-pin connector and power mode switch to control the internal chassis power supply. Slot airflow direction Bottom of module to top of module Module cooling intake Bottom of chassis Module cooling exhaust Along top of chassis Power supply cooling system Forced air circulation through integrated fan Power supply cooling intake Rear of chassis Power supply cooling exhaust Top of chassis Minimum chassis cooling clearances 44.45 mm (1.75 in) Rear 76.20 mm (3.00 in) Sides 44.45 mm (1.75 in) |
