| General Information: Models Covered: USB-6212 BNC, USB-6212 Mass Termination, USB-6212 Spring Terminal. Warranted Specifications: Performance under stated conditions covered by the warranty. Typical Specifications: Performance met by most models. Nominal Specifications: Based on design and testing. Analog Input: Channels: 8 differential or 16 single-ended. ADC Resolution: 16 bits. Sample Rate: Up to 400 kS/s. Input Range: ±0.2 V, ±1 V, ±5 V, ±10 V. CMRR: 100 dB (DC to 60 Hz). Input Impedance: >10 GΩ in parallel with 100 pF (device on), 1,200 Ω (device off). Overvoltage Protection: ±30 V (device on), ±20 V (device off). Analog Output: Channels: 2. DAC Resolution: 16 bits. Maximum Update Rate: 250 kS/s per channel. Output Range: ±10 V. Output Current Drive: ±2 mA. Overdrive Protection: ±30 V. Digital I/O and PFI: Channels: Up to 32 digital I/O. PFI Functionality: Static digital input/output, timing input/output. Debounce Filter Settings: Various options from 125 ns to 2.56 ms. Input Voltage Protection: ±20 V on up to 8 pins. General-Purpose Counters/Timers: Counters/Timers: 2. Resolution: 32 bits. Measurement Types: Edge counting, pulse, period, etc. Base Clocks: 80 MHz, 20 MHz, 0.1 MHz. FIFO Size: 1,023 samples. Power Requirements: Input Voltage on USB Port: 4.5 V to 5.25 V. Typical Current: 320 mA at 4.5 V (no load), 400 mA (maximum load). Environmental: Operating Temperature: 0 °C to 45 °C. Storage Temperature: -20 °C to 70 °C. Humidity: 10% RH to 90% RH, non-condensing. Maximum Altitude: 2,000 m. Pollution Degree: 2. Physical Characteristics: Dimensions: BNC: 23.5 cm × 11.2 cm × 6.4 cm. Mass Termination: 19.3 cm × 9.4 cm × 3.1 cm. Screw Terminal: 16.9 cm × 9.4 cm × 3.1 cm. Weight: BNC: 950 g. Mass Termination: 227 g. Screw Terminal: 206 g. Calibration: Warm-up Time: 15 minutes. Calibration Interval: 1 year. |
