| Key product |
| AC Input Input rating100 to 240 VAC, 50/60 Hz, 7 to 3.5 AOperating voltage range 90 to 264 VAC Nominal input frequency 50 Hz/60 Hz Operating frequency range 47 to 63 Hz Efficiency 78% typical Over-current protection Internal fuse in line Main power disconnect The AC power cable provides main power disconnect. Do not position the equipment so that it is difficult to disconnect the power cord. The front-panel power switch causes the internal chassis power supply to provide DC power to the PXI Express backplane.
Chassis Cooling Forced air circulation (positive pressurization) through two 150 CFM fans Module slot airflow direction Bottom of module to top of module Module intake Bottom of chassis Module exhaust Top, right side of chassis Slot cooling capacity 58 W for slot 2 to slot 8; 38 W for slot 9 Power supply cooling Forced air circulation through integrated fans Power supply intake Front and left side chassis Power supply exhaust Rear of chassis |
