| Key product |
| Analog Input Channels: 4 differential or 8 single-ended Resolution: 14-bit ADC Maximum Sample Rate: 20 kS/s aggregate Input Range: ±10 V Absolute Accuracy: 6 mV typical at full scale System Noise: 0.7 mVrms Input Impedance: >1 GΩ Overvoltage Protection: ±30 V (powered-on), ±20 V (powered-off) Analog Output Channels: 2 Resolution: 14-bit DAC Output Range: ±10 V Maximum Update Rate: 5 kS/s simultaneous per channel Output Current Drive: ±5 mA Slew Rate: 3 V/μs Output Impedance: 0.2 Ω Absolute Accuracy: 9.1 mV typical at full scale Digital I/O Digital Lines: 13 Ports: Port 0 (8 lines), Port 1 (4 lines), Port 2 (1 line) Input Voltage Range: 0 to 5 V (powered on), 0 to 3.3 V (powered off) Output Voltage Range: 0 to 5 V Direction Control: Programmable per channel Output Driver Type: Programmable as open collector or active drive Counter/Timer Number of Counters: 1 Resolution: 32-bit Counter Measurements: Edge counting (rising or falling) Counter Direction: Count up Maximum Input Frequency: 5 MHz Power Source Output Voltage: +5 V, ±3% Maximum Current: 150 mA Overcurrent Protection: 200 mA Short Circuit Current: 50 mA Bus Interface USB Specification: USB Full Speed (12 Mb/s) Physical Characteristics Dimensions: 75.4 mm × 86.2 mm × 23.6 mm (without screw terminal plugs) Weight: 83 g (without plugs), 105 g (with plugs) Environmental: Operating temperature 0 to 45 °C, storage -40 to 85 °C Safety and Standards Compliance: IEC 61010-1, UL 61010-1, CSA 61010-1 |
